Adyen

Why connect Adyen for Transactions

Connect Adyen as a source so Reveal can import payment activity from your Adyen merchant account into Transactions. After the connection is complete, Reveal imports historical data and continues to monitor live activity so you can:

  • Track authorization and decline rates for Adyen Gateway Accounts
  • Diagnose failures, including 3D Secure authentication outcomes and disputes
  • Act on payment-performance changes from Insights and Alerts

The same Adyen source can also feed Settlements, so finance teams can reconcile payouts, track unsettled volume, and analyze processing fees.

Note

Connecting Adyen does not change how payments are processed. Reveal reads data from Adyen; it does not modify live payment flows.

For payment authorization analytics, See Get started with Transactions. For Payout Reconciliation, see Connect Adyen for Settlements.

Ways to connect Adyen

Chargebee Reveal offers both onboarding and self-serve connection options with Adyen.

Note

  • For assisted Adyen integration, contact your dedicated Account Manager (AM) to setup Adyen as a source in Reveal

  • For self-serve integration, you can refer to the guide below and follow the steps to connect Adyen manually. The following section is a step-by-step guide to help you set up Adyen manually.

Self-serve integration

Complete these 3 steps in your Adyen account at a merchant account level:

  1. Create API credentials in Adyen
  2. Add Adyen as a source in Reveal
  3. Configure reports for Reveal

Create API credentials in Adyen

Note

Adyen's Customer Area can change. The instructions in this section are a working guide for connecting Reveal. Refer to Adyen's documentation for creating a Report service user for the updated steps.

Create new API credentials in your Adyen dashboard to integrate with Chargebee Reveal.

  1. Log in to your Adyen Dashboard and select the appropriate merchant account from the top left corner of your dashboard.
  2. On the left navigation bar, select Developers > API Credentials
  3. On the API credentials page, click Create New Credential.
  4. On the Create API Credential modal, you will see 2 credential types. Web service user and Report service user.
  5. Select Report Service User as the credential type. Click Create Credential.
  6. On the Configure API Credentials page, scroll down to the Server Settings section and copy the API key in the API key field. Ensure to store the API key in your system, as you will not be able to see it later.
  7. Scroll further down to the Permissions section. Under the Reports drop-down, ensure you have checked the option for Merchant Report Download Role.
  8. In the Accounts section, ensure you have chosen the right account group and merchant account.
  9. Lastly, click Save Changes. This will store and enable the newly generated API key.
  10. You have now created the API credential for Report service user. To create the API credential for Web service user, repeat steps 1 to 8. Once securing both the API keys in your system, you can proceed to add Adyen as a source in your Reveal account.

Add Adyen as a source in Reveal

Follow these steps:

In your Reveal dashboard,

  1. Navigate to Sources > Add source.
  2. Select Adyen.
  3. On the add source page of Adyen, fill in the respective fields.
  • API Key (Web Service) - Paste the API key generated from Adyen
  • API Key (Reporting) - Paste the API key generated from Adyen
  • Merchant Account Name as configured on your Adyen account
  • Company Account Name as configured on your Adyen account
  • Add an Alias name for this integration
  1. Click on Connect & Proceed.

Configure reports for Reveal

Note

Adyen's Customer Area can change. Refer to Get reports automatically for the latest steps to turn on automatic generation. The instructions in this section are a working guide for connecting Reveal.

You need the following report configurations for effective Transactions data and insights:

  • Received Payments Report
  • Payment Accounting Report
  • 3D Secure Authentication Report
  • Dispute Transactions Report
  • Settlement Details Report

Follow the same steps below for each report listed above:

  • Go to Adyen Account > Reports.
  • Search for the report name in the search bar.
  • Select the report.
  • Click on Column Configuration. Select the checkbox in the table header. Ensure all columns are selected and click on Save configuration.
  • Go to Generated reports tab, click on Manage Report > Automatic > Automatic Generation (On) and File Type as .CSV.
